Flame Retardant Polyamide 66 Compound
Flame-retardant polyamide 66 compound (BATOMID) is a type of engineering thermoplastic designed to enhance thermal resistance and provide flame-retardant properties. This flame-retardant polyamide 66 compound is highly practical due to its use of specialized technology for creating halogen-free flame-retardant features, making it suitable for producing heat-resistant parts through the plastic injection molding process. Its flame resistance, reduced smoke production, and high durability make it ideal for environments with a risk of ignition, showcasing just a few of the thermal properties of this widely used compound in the electrical and electronics, as well as automotive industries. The knowledge-based company Baspar Tose’e Davam Shimi, in addition to the existing grades, is capable of custom designing and producing various types of flame-retardant polyamide 66 compounds to meet the diverse needs of its customers.
Technical Specifications
Flame-retardant polyamide 66 compound is a type of engineering blend that not only offers excellent resistance at high temperatures but also produces less smoke and flame in ignitable environments. Other features of flame-retardant polyamide 66 compound include high strength and modulus, dimensional stability, and wear resistance over both short and long-term periods. With an oxygen index of 33 percent and a flammability rating according to UL 94 ranging from V-2 to V-0, as well as a Glow Wire standard approval at 960 degrees Celsius, this compound is particularly significant for use in flammable environments. Bespaar Tose’e Davam Chimi Company use the latest technologies to design and produce various flame-retardant compounds, both halogenated and non-halogenated, aimed at enhancing safety and reducing the risk of damage to components in ignitable settings. The engineering industry's need for durable parts in high-temperature environments drives us to consistently supply and produce high-quality, customizable flame-retardant polyamide compounds. Flame-retardant engineering polyamide 66 compounds are available in a variety of colors, including black, for sale in both domestic and international markets. The engineers at Bespaar Tose’e Davam Shimi are continually working to provide the most suitable grades of flame-retardant polyamide 66 compounds for the fabrication of pre-formed and final parts through plastic injection molding. It is worth noting that designing and producing custom formulations, as well as consulting and offering suggestions for optimal processing conditions, are additional services provided by Bespar Tose’e Davam Shimi, carried out by the company's research and development team. Below are some of the properties of flame-retardant polyamide 6 compounds.
Variety of Grades
| Specification | Unit | BATOMID6 | |
|---|---|---|---|
| FR-10WNC | |||
| Physical Properties | Type | Flame retardantV0-rated | |
| Density | g/cm3 | 1.14 | |
| Shrinkage | % | ≤0.1 | |
| Moisture absorption | % | 0.5 | |
| Mechanical Properties | Tensile strength at break | MPa | 75 |
| Elongation at break | % | 11 | |
| Tensile modulus | MPa | 2800 | |
| Izod impact, notched | kJ/m2 | 4 | |
| Hardness | 80 | ||
| Temporal Properties | Melting temperature (10K/min) | ͦC | 250 |
| Heat deformation temperature (0.45 MPa) | ͦC | 220 | |
| Heat deformation temperature (1.8 MPa) | ͦC | 190 | |
| Flame retardancy | GEFI, 2mil | C | 850 |
| UL-94 | V0 |
Process Parameters
Applications
Automotive Industry
Electricity and Electronics
Home Appliance Industry
